TDP

Up to 11W

Display

Graphic card

Integrate

Multi displays

Support 2 Displays

Interface

1 x HDMI-Out, 1 x DP  or VGA

System

Memory

Onboard DDR4 2GB/4GB

Storage

1 x M.2 Key M 2280 for NVME SSD           Onboard EMMC 8/16/32/64GB

(Optional)

OS

KOS

WatchDog

Support

Auto Power On

Support

RTC

Power on at specific time everyday

Power Input

12v DC-In (2.5/5.5 DC Jack)

Dimension

168mm(L) x 120mm(W) x 33mm(H)

Operating Temp.

0~40C

Operating

Humidity

10%~90% non-condensing

Storage Temp

-20~70C

Operating

Humidity

5%~95% non-condensing

Network

Lan IC

1 x Realtek Lan IC or 2 x Realtek Lan IC

Lan Interface

1.0Gbps

Lan Connector

2 x RJ45 Ports or 1 x RJ45 Port

Wireless Type

WIFI5/WIFI6

Wireless

Interface

M.2 2230 Key E With PCIe,USB2.0

4G/5G

N/A

I/O interface

Serial Port

N/A

USB

4 x USB3.2  ( 5Gbps)  ，2 x USB2.0 (Colay  RJ45), 1 x TYPE-C  (USB2.0)

Button

1 x PowerButton, 1 x Reset KEY

SIM CARD

N/A

AUDIO

1 x 3.5mm Audio Jack (2 In 1)

1 x 3 5mm Mic In

POWER

1 x 2.5/5.5 DC-IN Connector

L0E2-A

FT-E2000Q/2GB DDR4/8GB EMMC/HDMI/VGA/4*USB3.0/2*USB2.0/1*RJ45

L0E2- B

FT-E2000Q/2GB DDR4/16GB EMMC/HDMI/DP/4*USB3.0/2*USB2.0/1*R45

L0E2-C

FT-E2000Q/4GB DDR4/32GB EMMC/HDMI/DP/4*USB3.0/2*USB2.0/1*R45

L0E2- D

FT-E2000Q/4GB DDR4/64GB EMMC/HDMI/VGA/4*USB3.0/2*USB2.0/1*R45

L0E2- E

FT-E2000Q/4GB DDR4/64GB EMMC/HDMI/DP/4*USB3.0/2*RJ45/CB515NF

Adapter

x 1

User Manual

x 1

Wall-mounting

x 1
